Introduction
The manual pallet truck inserts its cargo fork into the pallet hole when in use. The hydraulic system is driven by people to realize the lifting of pallets. Handling is done by manual pulling. It is the simplest, most effective and most common loading, unloading and handling tool in pallet transportation.
Advantages
- Thickened steel plate
- Strong spring
- Cast steel PU wheel or nylon wheel are optional
- Integral casting cylinder
- Adjustable connecting rod
- Strengthen the rocker arm
Parameters
| Type | PT-2 | PT-2.5 | PT-3 | PT-5 | PT5-1 |
|---|---|---|---|---|---|
| Capacity (kg) | 2000 | 2500 | 3000 | 5000 | 5000 |
| Height when lowered (mm) | 85 | 85 | 85 | 85 | 85 |
| Drive wheel size (mm) | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 |
| Driven wheel size (mm) | Φ80*70 | Φ80*70 | Φ80*70 | Φ80*70 | Φ80*70 |
| Total height (mm) | 1224 | 1224 | 1224 | 1224 | 1224 |
| Total length (mm) | 1533/1603 | 1533/1603 | 1533/1603 | 1533 | 1603 |
| Fork length (mm) | 1150/1220 | 1150/1220 | 1150/1220 | 1150 | 1220 |
| Fork out width (mm) | 550/685 | 550/685 | 550/685 | 550 | 685 |
| Turning radius (mm) | 1266/1366 | 1266/1366 | 1266/1366 | 1266 | 1336 |
| Self-weight (kg) | 61.8/65.2 | 63.8/68.2 | 65.8/69.2 | 114 | 120 |
PARTS SHOW
Ergonomic Handle
Nylon Wheel
PU Wheel
Double Bearing Wheel
Height Adjustable
Integral Casting Pump Station
