introduction

Stock Picker is fully electric, semi-electrically available. All electric is electric lift, electric walking; Semi-electric is electric lifting, walking by hand. 300kg-1000kg load capacity,can be customized. 1.6-5m Lifting , The table size can be customized.

Stock Picker has a spacious operating platform and high quality skid surface, It reflects good stability,guarantee the safety of operation at heights. And it is suitable for single-person operation and is used for picking and placing items in small spaces such as warehouses, workshops, elevators, supermarkets, and subway stations.

Features

  • Using advanced foreign control systems, The core components include the electronic control system, the pump station assembly, and the drive unit all using original or imported assemblies;

  • The drive motor has automatic braking function and has good climbing ability;

  • The state of charge machine is restricted to work, In order to ensure the safety of users;

  • Overload limit;

  • Set an emergency descent valve device, no security risks;

  • Set fault self-diagnosis function;

  • Emergency stop button;

  • Emergency drop button;

  • Charging indicator, voltage display, external smart charger, easy to understand battery level at any time, greatly extend battery life;

  • Double brake double brake disc;

  • Safety maintenance support.

Advantages

  • The heaviest capacity --10000T oil hydraulic press in hook industry.
  • One-time shaping by die forging
  • Own EU CE certification, US ABS certification, China Classification Society certification, etc.
  • 200% load test

Parameters Table

Model ZDYT3-3.5T ZDYT3-4.0T ZDYT3-4.5T
Pated load 300kg
Worker 1
Working height(H1) 5.50m 6.00m 6.50m
Platkform 3.50m 4.00m 4.50m
height(H2)
Overall length(A) 1.56m
Overall width(AC) 0.76m
Overall height(B) 1.64m 1.81m 1.99m
Plalform size 0.93m×0.70m
Ground clearance 0.04m
Wheel bas 1.23m
Minimum turning radius 0
Power source 2×24VDC/0.4kw
Lift power 24VDC/2kw
Machine running speed (Stowed status) 4.0km/h
Machine running speed(Lifting status) 1.1km/h
Lifting/Descending Speed 20/18 sec 22/19 sec 24/21 sec
Battery 2×12V/120Ah
Charger 24V/10A
Maximum climbing 25%
Working angle 1.5°
Rear tyre ¢230б×80mm
Front tyre 6 in
Weight 642kg 662kg 682kg

Parts Details

202201rhfo

Cable wiring

202201mmpd

Limit switch

202201ngeb

Quick connection plug

202201sklm

Control handle

202201guez

Electric moving wheel

202201ywst

Guardrail lock
